Junaid Metals, a well-respected manufacturer and supplier located in Manama, Bahrain, has built a solid reputation for providing top-notch Stainless Steel 904L Hex Bars. These bars are essential for industries that demand outstanding corrosion resistance and mechanical strength. With a strong commitment to precision manufacturing, rigorous quality control, and compliance with international standards, Junaid Metals guarantees products that perform reliably even in the toughest environments. They cater to various sectors, including chemical processing, marine engineering, petrochemicals, and construction, offering customized solutions that meet specific project needs. Their Stainless Steel 904L Hex Bars are prized for their durability, stability, and consistent performance in aggressive and corrosive settings.
These hex bars are crafted from a high-alloy, low-carbon austenitic stainless steel, enriched with elevated levels of nickel, chromium, molybdenum, and copper. This unique blend provides remarkable resistance to strong acids, pitting, and crevice corrosion. On the mechanical side, they boast good tensile strength, excellent toughness, and reliable formability, even at high temperatures. Their non-magnetic properties and superior weldability add to their versatility. The perfect mix of corrosion resistance, mechanical stability, and durability makes Stainless Steel 904L Hex Bars an ideal choice for demanding applications in harsh industrial conditions.
| Specifications | ASTM B649 / ASME SB 649 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Stainless Steel Round Bar | Outside Diameter in the range of 4mm to 500mm |
| Stainless Steel Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Stainless Steel Hex Bar | 18mm – 57mm (11/16″ to 2-3/4″) |
| Stainless Steel Square Bar | 18mm – 47mm (11/16″ to 1-3/4″) |
| Stainless Steel Flat Bar | 1/2″ to 10″ in thickness range of 2 mm to 150mm, Custom Size Stainless Steel Flats available |
| Range | 3.17 MM TO 350 MM DIA |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Finishing | Bright, Polish & Black |
| Form of | Hex, Wire (Coil Form), Wiremesh, Billet, Ingot, Forging Etc., |
| Other Services | Machining (CNC), Centreless Grinding (CG), Heat Treatment, Annealing, Pickling, Polish, Rolling, Forging, Cutting, Bending, Minor Fabrication, |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
| SS 904L | Min | – | – | – | – | – | 19 | 4 | 23 | 1 |
| Max | 0.02 | 2 | 1 | 0.045 | 0.035 | 23 | 5 | 28 | 2 |
| Grade | Tensile strength (MPa) | Yield Strength 0.2% Proof(MPa) | Elongation (% in 50mm) | Hardness – Brinell |
| 904L | 490 | 220 | 36 | 70-150 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 904L Hex Bar offers excellent corrosion resistance, especially against pitting, crevice, and stress corrosion cracking. Its high nickel and chromium content make it ideal for harsh environments like chemical processing, marine, and power plants. The hexagonal shape provides enhanced strength and machinability, ensuring durability and reliability in industrial applications.
SS 904L outperforms many stainless steels, such as 304 and 316, in corrosion resistance due to its higher nickel and molybdenum content. This composition enhances resistance to chloride-induced pitting and crevice corrosion, making it ideal for environments with high chloride concentrations or acidic exposure, such as chemical and marine applications.
SS 904L Hex Bar is commonly used in the chemical, petrochemical, marine, and pharmaceutical industries. It is ideal for applications such as heat exchangers, reactor vessels, pressure vessels, and piping systems, where resistance to corrosion, especially in acidic and chloride-rich environments, is critical for long-term durability and performance.
Across various industries, Stainless Steel 904L Hex Bars are widely utilized due to their exceptional corrosion resistance and structural integrity. In chemical and petrochemical plants, they serve as heat exchangers, processing equipment, and components that come into contact with strong acids and chlorides. The marine industry depends on them for seawater-resistant fittings, fasteners, and structural components. In the oil and gas sector, they are essential in high-pressure and corrosive environments. Additionally, 904L Hex Bars are also used in pharmaceuticals, pulp and paper machinery, and architectural structures.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
