Welcome to Junaid Metals, your reliable partner in Manama, Bahrain for superior stainless steel solutions. We specialize in providing high-quality Stainless Steel 317l Hex Bar and Rod, materials trusted by industries that demand exceptional performance. Understanding the harsh conditions our local projects often face, we supply 317l for its outstanding resilience. Our commitment is to deliver not just a product, but a foundation for your most durable and critical applications, backed by our expert knowledge and dependable service right here in the heart of the Gulf.
The strength of Stainless Steel 317l lies in its carefully balanced composition, which includes higher levels of chromium, nickel, and molybdenum, along with an addition of nitrogen. This specific blend grants it superior resistance to corrosive substances like acids and chlorides, particularly in high-temperature settings. Mechanically, this alloy offers excellent tensile strength and good ductility, allowing it to be fabricated into complex components without sacrificing its structural integrity, making it a reliably tough material for challenging environments.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317l | 0.03 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 317l | 8 | 1450 ℃ | 515 | 205 | 40 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 317L Hex Bars/Rods are commonly used in chemical processing, marine environments, pharmaceuticals, and food processing due to their excellent corrosion resistance and high strength. They are ideal for handling aggressive chemicals, including sulfuric acid, bleaching solutions, and pulp liquor. In construction, they are used for structural components and fittings.
SS 317L Hex Bars/Rods typically range from 6 mm to 100 mm in diameter, with lengths up to 6 meters. Tolerances generally conform to ±0.5 mm for diameter. These dimensions and tolerances ensure precision for machining, making them ideal for applications requiring high strength, corrosion resistance, and tight fit.
The high chromium (18-20%) and molybdenum (3-4%) content in SS 317L enhances its resistance to pitting and crevice corrosion by forming a passive oxide layer that protects against chloride-induced degradation. The low carbon content further reduces the risk of stress corrosion cracking, ensuring durability in harsh chloride environments.
Stainless Steel 317l Hex Bar and Rod are essential in sectors where failure is not an option. You will find them forming the backbone of chemical processing equipment, pharmaceutical manufacturing plants, and components within oil and gas refineries. Their exceptional resistance to pitting and crevice corrosion also makes them ideal for marine applications, such as boat fittings and offshore platforms. From architectural elements in coastal areas to critical parts in pollution control systems, this alloy provides the long-lasting durability needed for success.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Junaid Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manama, Bahrain
