Stainless Steel 316Ti Forgings are highly sought after for their outstanding resistance to corrosion, impressive strength at high temperatures, and remarkable durability. These qualities make them perfect for tough industrial, chemical, and marine environments. As a titanium-stabilized austenitic stainless steel, grade 316Ti excels in resisting intergranular corrosion and holds up well under high heat. These forgings are known for their precise dimensions, excellent mechanical performance, and long-lasting service life, making them ideal for critical applications like pressure vessels, piping systems, heat exchangers, and structural components in high-performance sectors. When it comes to strength, reliability, and the ability to withstand harsh conditions, Stainless Steel 316Ti Forgings are a trusted choice.
The composition of Stainless Steel 316Ti Forgings primarily includes iron, along with about 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, plus titanium for stabilization. This titanium addition helps prevent chromium carbide from forming during welding or when exposed to heat for extended periods, ensuring resistance to intergranular corrosion. The material boasts excellent mechanical properties, such as high tensile strength, toughness, and stability at elevated temperatures. Stainless Steel 316Ti Forgings maintain their dimensional accuracy and structural integrity even under thermal cycling and mechanical stress, making them perfect for precision industrial components that demand durability, corrosion resistance, and long-term reliability.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Yes, Stainless Steel 316Ti can be forged into custom shapes. Its excellent formability and resistance to corrosion make it suitable for creating complex designs required in various industries.
Yes, Stainless Steel 316Ti forgings are ideal for structural applications. Their excellent corrosion resistance, high strength, and ability to withstand extreme environments make them suitable for marine, chemical, and architectural structures.
Yes, Stainless Steel 316Ti forgings are ideal for structural applications. Their excellent corrosion resistance, high strength, and ability to withstand extreme environments make them suitable for marine, chemical, and architectural structures.
These forgings find extensive use in industries like chemical processing, petrochemical, pharmaceuticals, marine, and power generation. Their exceptional corrosion resistance and stability at high temperatures make them ideal for applications involving pumps, valves, flanges, heat exchangers, pressure vessels, and structural components that face aggressive environments. Forged components provide enhanced strength and toughness compared to their cast or fabricated counterparts, ensuring they can handle the demands of challenging applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
