Situated in the industrial heart of Manama, Junaid Metals has built a reputation as a trusted partner for industries across Bahrain and beyond, specializing in the supply of high-quality metal components. We take pride in offering a reliable inventory of Stainless Steel 304L Hex Bar and Rod, materials chosen for their exceptional balance of durability, corrosion resistance, and versatility. For any project demanding precision and longevity, our 304L products provide a solid foundation, backed by our commitment to customer service and expert technical support.
The composition of 304L stainless steel is carefully formulated for superior performance, featuring a low carbon content that enhances its weldability and resistance to corrosion. This alloy, primarily chromium and nickel, provides excellent mechanical properties, including good tensile strength and impressive ductility. These characteristics allow the hex bars and rods to be easily machined and fabricated into complex components without sacrificing their inherent toughness, making them a practical and dependable choice for demanding environments.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 304L | 8.0 g/cm3 | 1400 °C (2550 °F) | 485 | 170 | 40 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 304L hex bars/rods are typically available in sizes ranging from 3.17mm to 350mm in diameter, with lengths of 2 to 7.5 meters. These bars come in various finishes, such as polished or cold-drawn. Custom sizes and specifications can also be produced upon request to meet specific needs.
Yes, SS 304L hex bars/rods are highly weldable and suitable for fabrication into complex shapes. Their low carbon content minimizes carbide precipitation during welding, reducing the risk of corrosion. This material's excellent ductility and toughness allow easy forming, machining, and fabrication, making it ideal for intricate designs and applications.
SS 304L has lower carbon content than standard 304, reducing carbide precipitation and enhancing corrosion resistance, particularly after welding. While slightly lower in strength compared to higher-carbon grades like 304 or 316, it maintains excellent toughness and durability. SS 316 offers superior corrosion resistance in chloride environments due to added molybdenum.
The uses for our Stainless Steel 304L Hex Bar and Rod are incredibly diverse, finding a home in everything from the intricate components of marine hardware and architectural fittings to the stringent requirements of the food processing and pharmaceutical industries. Their excellent corrosion resistance makes them ideal for chemical processing equipment, while their strength and machinability are valued in automotive and aerospace applications. Essentially, wherever a combination of hygiene, strength, and resistance to the elements is needed, you’ll find 304L providing a reliable and long-lasting solution.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Junaid Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manama, Bahrain
