For years, Junaid Metals in Manama, Bahrain has been a trusted name for industrial materials, built on a foundation of reliability and deep local expertise. Our specialty is providing high-performance alloys like the Stainless Steel 15-5 PH Hex Bar and Rod. We understand that your projects demand materials you can count on, which is why we are committed to supplying products that combine exceptional strength with superior corrosion resistance, directly supporting the growth and precision of industries across the region and beyond.
The composition of 15-5 PH stainless steel is a key to its performance, primarily consisting of chromium and nickel, with additions of copper and niobium. This specific blend allows it to be heat-treated to achieve impressive mechanical properties. After this treatment, it offers a high level of strength and hardness, excellent resistance to corrosion, and good toughness. This combination makes it significantly more robust than many standard stainless steels, able to withstand heavy loads and harsh environments without compromising its structural integrity.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Store Stainless Steel 15-5 PH hex bars and rods in a clean, dry, ventilated area, elevated on racks, with protective covers, separated from other metals, and handled carefully.
Stainless Steel 15-5 PH hex bars excel in wear-resistant applications due to their high strength, toughness, excellent corrosion resistance, and ability to maintain hardness after precipitation-hardening heat treatment.
Common challenges with Stainless Steel 15-5 PH hex bars include susceptibility to stress corrosion cracking in chloride environments, limited ductility in hardened conditions, higher machining difficulty, and potential distortion during heat treatment.
The unique strength and corrosion resistance of 15-5 PH Hex Bar and Rod make it an ideal choice for demanding applications. You will often find it in critical aerospace components, such as landing gear parts, and within the high-stress environment of turbine engines. It is also essential in the oil and gas industry for valves and pump shafts, and is widely used for medical instruments and chemical processing equipment. Essentially, it is the material of choice wherever a part must be both incredibly strong and highly resistant to rust and oxidation.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Junaid Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manama, Bahrain
