Situated in Manama’s dynamic industrial landscape, Junaid Metals has built a solid reputation as a trusted manufacturer and supplier of specialty steels. We take particular pride in our precision-crafted Maraging Steel bar and rod, a material engineered for the most demanding challenges. Our commitment is to provide local and international industries with robust, high-performance components that form the backbone of critical projects, ensuring reliability and superior strength right from the heart of Bahrain.
This exceptional steel derives its strength from a unique composition that is low in carbon but rich in nickel, cobalt, molybdenum, and titanium. Instead of relying on carbon for hardness, it achieves its remarkable properties through a special heat treatment process called age hardening. This results in an outstanding combination of very high tensile strength and excellent toughness, all while maintaining good machinability in its annealed state before the final aging treatment.
| Standard : | AMS, AMS, API |
| Specification : | ASTM A538, AMS 6512, Mil-S-46850D, BS S162, DTD 5212, MSRR 6551, MAT 102, MIA 101 |
| Size : | 20mm x 1200 x 500 |
| Specialize Sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Maraging Steel 250/ 300 / 350 (UNS-K92890, K93120, S35000) |
| Grade | C | Mn | Si | Co | Fe | Ni | Mo | Ti | Al |
| Maraging C250 | .03max max | .10max max | .10max max | 7.50 max | Bal | 18.50 min | 4.80 max | .40 max | .10 max |
| Maraging C300 | .03max max | .10max max | .10max max | 9.0 max | Bal | 18.50 min | 4.80 max | .60 max | .10 max |
| Maraging C350 | .03max max | .10max max | .10max max | 12.0 max | Bal | 18.50 min | 4.80 max | 1.40 max | .10 max |
| Grade | Density | Average Coefficient of Thermal Expansion | Modulus of Elasticity |
| Maraging 250 | .289 lbs./cu.in | 5.6 x 10-6 in./ in./ ºF | 5.6 x 10-6 in./ in./ ºF |
| Maraging 300 | .289 lbs./cu.in | .289 lbs./cu.in | 292 lbs./cu.in |
| Maraging 350 | .289 lbs./cu.in | 6.3 x 10-6 in./ in./ ºF | 29.0x 10-6 psi |
| STANDARD | UNS | Material No | AMS | ASTM | Mil-S | BS | DTD | MSRR |
| Maraging Steel | K92890, K93120, S35000 | – | 6512 | A538 | 46850D | S162 | 5212 | 6551 |
Maraging Steel Rods are typically available in sizes ranging from 0.125 inches (3.175 mm) to 12 inches (305 mm) in diameter, with lengths varying from 12 inches (300 mm) to 20 feet (6 meters).
Yes, Maraging steel bars can be welded, but they require careful control of heat input and pre/post-weld heat treatment to avoid compromising the material’s strength and toughness.
Maraging steel rods are typically available in diameters ranging from 0.25 inches to 8 inches. Common finishes include cold drawn, polished, or ground, with standard lengths between 12 and 24 feet.
The unique qualities of our Maraging Steel make it indispensable in fields where failure is not an option. You’ll find it at the core of aerospace components like landing gear and engine shafts, in high-stress tooling for molding and extrusion dies, and within critical defense applications. It’s also vital for manufacturing parts in robotics and high-performance automotive systems, proving its worth anywhere exceptional strength-to-weight ratio and reliable performance under extreme stress are absolutely essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
