Located in the heart of Manama, Bahrain, Junaid Metals has built a strong reputation as a trusted manufacturer and supplier of high-performance components. We specialize in producing superior Inconel 625 forgings, a testament to our commitment to quality and reliability. Our advanced forging processes are designed to meet the rigorous demands of various industries, ensuring that every component we deliver offers exceptional strength and resistance. We take pride in supporting our clients with robust solutions that stand up to the most challenging environments.
Inconel 625 is distinguished by a nickel-chromium base, strengthened with significant additions of molybdenum and niobium. This specific composition gives the alloy its remarkable mechanical properties, including very high tensile and yield strength, along with outstanding toughness. It maintains these excellent characteristics across an extremely wide temperature range, from cryogenic conditions up to intense heat. This combination ensures the material performs reliably under immense stress and pressure.
Specifications ASTM B564 / ASME SB564, AMS 5666
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | C | Mn | Si | S | Al | Ti | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 0.40 max | 0.40 max | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Alloy 625 | N06625 | 2.4856 | NC22DNB4M | NiCr22Mo9Nb | NCF 625 | NA 21 | ХН75МБТЮ | ЭИ602 |
Temperature control during forging of Inconel 625 ensures optimal material properties, preventing brittleness and maintaining its strength and ductility. Proper temperature management also enhances uniformity, reducing defects and improving overall quality.
Inconel 625 Forgings are expensive due to the high cost of raw materials and complex manufacturing processes. Additionally, their workability can be challenging at certain temperatures, requiring specialized equipment and techniques.
To determine if Inconel 625 Forgings meet your needs, compare their material properties with your application requirements and consult with suppliers for tailored solutions.
Forged components made from Inconel 625 are essential in sectors where failure is not an option. You will find them in critical applications such as jet engine exhaust systems, gas turbine blades, and high-strength ducting for aerospace. In the marine world, they resist corrosion in propeller blades and submarine fittings, while the chemical processing industry relies on them for reactor vessels and heat exchangers. Their unique blend of strength and corrosion resistance makes them indispensable for demanding environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
