Nestled in the industrial heart of Manama, Junaid Metals has established itself as a trusted name for specialty alloys, with a particular expertise in high-performance Inconel 617 forgings. We understand that the most demanding industrial challenges require materials of exceptional integrity. That’s why our forged components are produced with meticulous care, ensuring they deliver the unparalleled strength and reliability our clients across the region have come to depend on for their critical applications in extreme environments.
The outstanding capability of Inconel 617 stems from its sophisticated composition, a precise balance of nickel, chromium, cobalt, and molybdenum. This alloy is specifically engineered to create a material with exceptional high-temperature strength and superb oxidation resistance. Even when subjected to intense heat for prolonged periods, it maintains remarkable mechanical stability and creep resistance, ensuring long-lasting structural integrity where ordinary metals would quickly fail.
Specifications ASTM B564 / ASME SB 564, AMS 5887
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | UNS | WNR. |
| Alloy 617 | N06617 | 2.4663 |
Temperature control during forging of Inconel 617 ensures optimal grain structure, improving its strength, durability, and resistance to thermal creep. Proper temperature management also prevents material defects like cracking or distortion, enhancing overall quality.
Inconel 617 forgings may experience reduced ductility at lower temperatures, limiting their ease of fabrication. Additionally, they can be costly due to the complex alloy composition and manufacturing processes.
Inconel 617 forgings require periodic inspections to detect signs of oxidation or wear, particularly at elevated temperatures. Regular cleaning and protective coatings can help maintain their performance in harsh, high-temperature environments.
These unique properties make Inconel 617 forgings indispensable in sectors where failure is not an option. You will find them at the core of gas turbine engines and combustion systems in the power generation industry, and within critical reactors and heat exchangers in petrochemical and chemical processing plants. Their resilience also makes them ideal for components in high-temperature nuclear reactors and various aerospace applications, proving essential wherever extreme heat and corrosive conditions are a constant challenge.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Junaid Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manama, Bahrain
