Welcome to Junaid Metals, your trusted partner in Manama, Bahrain for premium aluminium solutions. We pride ourselves on delivering excellence by manufacturing and supplying high-grade materials like the Aluminium 6101 T6 Bar/Rods. Known for their exceptional strength and reliability, these bars are the ideal choice for demanding industrial and commercial projects across the region. We are dedicated to providing not just a product, but a reliable foundation for your most important constructions, ensuring quality that you can build upon with confidence.
The Aluminium 6101 T6 grade is specifically formulated, primarily consisting of aluminium with controlled additions of magnesium and silicon. This precise composition is expertly heat-treated to the T6 temper, resulting in a material that boasts an excellent balance of strength and electrical conductivity. It offers impressive mechanical properties, including high tensile strength and good formability, while maintaining notable resistance to corrosion. This makes it a robust and durable choice for a wide array of structural and electrical applications.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Aluminum, Al | Magnesium, Mg | Silicon, Si |
|---|---|---|
| 98.9 | 0.60 | 0.50 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 97 MPa | 14069 psi |
| Yield strength | 76 MPa | 11023 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| INDIA | U.S.A. | BRITAIN | CANADA | GERMANY | RUSSIA | I.S.O. | FRENCH | NORTH AMERICA | DIN Nos. | |
|---|---|---|---|---|---|---|---|---|---|---|
| New IS | Old IS | (A.A.) | (B.S.) | (DIN) | – | – | – | UNS | DIN | |
| 63401 | 91E | 6101 | 91E | D50S | E.Al.Mg.Si 0.5 | – | – | – | A96101 | 3.2315 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6101 T6 bars are recyclable. Aluminium, including alloys like 6101 T6, can be recycled indefinitely without losing its properties, making it an environmentally friendly material for sustainable manufacturing.
Yes, Aluminium 6101 T6 rods can be customized in size and length to meet specific requirements. Manufacturers often offer various diameters, lengths, and finishes, allowing the rods to be tailored for different applications.
To select the right Aluminium 6101 T6 bar or rod, consider factors like strength requirements, electrical conductivity, corrosion resistance, weight, and intended application (e.g., electrical, structural, aerospace, or industrial use).
The versatility of Aluminium 6101 T6 Bar/Rods makes them indispensable in numerous sectors. They are extensively used in the fabrication of busbars, electrical connectors, and various components for the power transmission industry due to their excellent conductivity. Beyond electrical uses, their strength and lightweight nature make them perfect for structural frameworks, architectural fittings, and heavy-duty components in transportation and machinery. Whether for a new power substation or a custom architectural design, this material provides a dependable and efficient solution.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Junaid Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manama, Bahrain
