Nestled in the heart of Manama’s bustling industrial landscape, Junaid Metals stands as a trusted partner for businesses seeking reliable material solutions. We take pride in supplying high-grade aluminium products, including the exceptionally versatile Aluminium 3003 Bar and Rods. Known for its superior workability and resilience, this alloy is a cornerstone for countless projects, and we are committed to delivering it with the quality and service our clients in Bahrain and beyond have come to expect.
The composition of Aluminium 3003 is a thoughtful blend, primarily aluminium strengthened with a manganese addition, which gives it a notable edge in strength over pure aluminium. This results in a bar and rod that boasts excellent mechanical properties, including good formability and commendable corrosion resistance. It’s a material that strikes a beautiful balance, being both strong enough for structural applications and malleable enough for detailed fabrication work without sacrificing its durability.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Cr | Cu | Fe | Mg | Mn | Other Total | Si | Ti | Zn |
| min. | Remainder | – | 0.05 to 0.20% | 0.7% | – | 1.0 to 1.5% | 0.15% | 0.6% | – | 0.10% |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 3003 | A93003 | 3.0517 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 3003 bars can be welded using standard welding techniques, such as TIG or MIG welding. Its excellent corrosion resistance and weldability make it ideal for various applications.
Yes, Aluminium 3003 bars and rods are suitable for hygienic and sanitary applications due to their corrosion resistance, lightweight nature, and excellent ability to withstand moisture and chemical exposure.
Aluminium 3003 bars have excellent corrosion resistance due to their manganese content, making them highly resistant to rust and chemical exposure in most environments, including marine and industrial settings.
The uses for these 3003 bars and rods are wonderfully diverse, making them a favourite among fabricators and engineers. You’ll commonly find them shaped into chemical equipment, storage tanks, and architectural details like decorative trim. They are also ideal for crafting kitchen utensils, heat exchangers, and general sheet metal work. Essentially, wherever a project calls for a combination of moderate strength, excellent workability, and a natural resistance to the elements, this aluminium alloy proves to be an outstanding and dependable choice.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
