For businesses in Bahrain and beyond seeking a reliable and strong aluminium solution, Junaid Metals in Manama proudly offers the 2017 BarRod. This particular alloy is a standout choice for demanding applications where exceptional strength is a primary concern. We understand that your projects require materials you can count on, which is why we ensure our Aluminium 2017 is supplied with consistent quality and the technical support needed to help your operations succeed, providing a solid foundation for even the toughest industrial challenges.
The strength of Aluminium 2017 comes from its composition, being a copper-based alloy that is known for its excellent mechanical properties. It is naturally a high-strength material that responds very well to heat treatment, achieving impressive levels of hardness and durability. While it offers lower resistance to corrosion compared to some other series, its key advantage lies in its remarkable machinability. This makes it a favorite for precision workshops, as it can be cut and shaped with excellent results, holding up well under stress.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others Each | Other Total |
| 2017 | Rem | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2017 | A92017 | 3.1325 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2017 can be welded, but it requires careful control due to its high strength and susceptibility to cracking. Specialized welding techniques like TIG or MIG are recommended.
To maintain Aluminium 2017, regularly clean with mild detergent and water, avoid abrasive materials, store in a dry environment, and prevent exposure to corrosive substances to preserve its strength and appearance.
Aluminium 2017 rods are typically sized by diameter and length. Common diameters range from 1/8 inch to several inches, while lengths can vary from a few feet to custom sizes based on needs.
This combination of high strength and superb machinability makes Aluminium 2017 BarRods incredibly versatile. You will commonly find them used in the aerospace industry for critical components, as well as in the manufacturing of heavy-duty parts like truck frames and suspension systems. They are also ideal for creating robust fittings for marine applications, various kinds of high-stress machinery parts, and even detailed architectural fixtures that require both strength and a fine finish. Essentially, wherever a project calls for a machinable metal that can bear a significant load, 2017 is an excellent contender.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
