Situated in the dynamic industrial landscape of Manama, Bahrain, Junaid Metals has built a strong reputation for reliability and precision. We are proud to specialize in providing high-performance materials, including the exceptionally durable Alloy C263 bar and rod. Our commitment is to supply industries with components that are not only robust but also precisely manufactured to meet the most demanding specifications, ensuring our clients receive materials that form the backbone of their most critical applications.
The strength of Alloy C263 lies in its specific composition, primarily nickel-chromium with additions of cobalt and molybdenum. This blend gives the material outstanding mechanical properties, including high tensile strength and excellent resistance to creep and fatigue, even when subjected to extreme temperatures. This combination ensures that bars and rods made from this alloy can withstand significant stress and maintain their integrity in challenging operational environments, making them a dependable choice for engineers.
| Standards : | AMS 5872 |
| Size Range : | 0.015″ Thk up to 2″ Thk |
| Thickness : | Range from .008″ to .0125″ |
| Length : | 2m, 2.44m, 3m, or as required |
| Width : | 10-2500mm |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Nimonic 263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Grade | Material Sheet | Temperature °C | Yield Strength 0.2 % (MPa) | Tensile Strength (MPa) | Elongation (%) | Hardness HV |
| Nimonic 263 | Nimonic 263 Round Bar Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Nimonic 263 Round Bar Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | – | |
| Nimonic 263 Round Bar Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 263 | 2.4650 | N07263 |
Yes, Alloy C263 bars are recyclable. As a high-performance alloy, it can be melted and reused for manufacturing new products, making it an environmentally friendly material in the long term.
Alloy C263 rods are available in various sizes ranging from 1/8" to 6" in diameter, with lengths typically up to 12 feet. Common finishes include hot-rolled, cold-drawn, and polished.
Yes, Alloy C263 (also known as Hastelloy C263) can be welded using appropriate techniques such as TIG or MIG welding, with careful control of heat to avoid carbide precipitation.
These impressive characteristics make Alloy C263 bar and rod ideal for aerospace and gas turbine applications, where components like turbine blades, rings, and casings must perform flawlessly under intense heat and pressure. Beyond aviation, this alloy is also perfectly suited for high-temperature industrial processing equipment. At Junaid Metals, we understand that our clients are building for the future, and we are dedicated to supplying the foundational materials that make such advanced engineering and innovation possible right here from Bahrain.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
